Konica Minolta Novo-Gloss Flex 60 Gloss-meter





Novo-Gloss Flex 60 is designed specifically to measure the gloss of surfaces that cannot be measured using traditional gloss-meters, the Novo-Gloss Flex 60 gloss-meter combines the functionality and reporting of an advanced gloss-meter with an ultra-lightweight remote measuring head. IMPROVED PERFORMANCE IN LOW GLOSS APPLICATIONS the Novo-Gloss Flex 60 has been designed specifically to measure low gloss surfaces. It features an additional measuring scale with a resolution 10 times greater than standard glossmeters. This increased resolution gives a far superior level of control of surface finish. The Novo-Gloss Flex 60 complies to ISO 2813 and ASTM D523 and measurements made with the instrument are compatible with traditional gloss-meters complying to these standards.

Unit Price: USD9,999/pc, contact us for latest pricing.

PDF Download Konica Novo-Gloss Flex 60 Brochure

PDF Download Konica Minolta Novo-Gloss Flex 60 Manual

Features

  • Fast measurement of all parameters. Full on-board statistics with graphical trend analysis and reporting.

  • Simultaneous measurement of all parameters, results are date and time stamped.

  • Displays full statistics for the number of readings in the current batch.

  • Graphical reporting for quick trend analysis.

  • Pass / fail parameters can be defined for instant identification of non-conformances

  • Easy Batching - User definable batch names and batch sizes for quicker and more efficient reporting

  • Rapid data transfer - Software-free data transfer. USB connection to PC instantly recognizes the device as a drive location which facilitates the quick transfer of files using Windows Explorer or similar.

  • Direct data input via Bluetooth - Instantly transmit measured readings directly to programs such as MS Excel on your PC / tablet to greatly simplify the reporting process

Specifications

GLOSS

GU GUh
Measurement range: 0-125 GU 0 -125 GUh (0-12.5 GU)
Resolution: 0.1 GU 0.1 GUh (0.01 GU)
Repeatability: 0.2 GU 0.5 GUh (0.05 GU)
Reproducibility: 0.5 GU 2.0 GUh (0.2 GU)
standards: ISO 2813, ASTM D523, ASTM D2457
DIN 67530, JIS 8741, JIS K 5600-4-7


INSTRUMENT SPECIFICATIONS

Operation

  • Full colour easy to read screen
  • Adjustable brightness
  • 6 button touch sensitive interface

Construction

  • Integrated calibration holder with in-position detector for
    error free calibration

Measurement

  • Fast measurement
  • Results batching with user definable names

Statistical Analysis

  • Max, min, mean, S.D.

Graphical Analysis

  • On board trend analysis

Power

  • Rechargeable lithium ion
  • 17+ hours operation
  • 14,000+ readings per charge

Memory

  • 8MB= >2000 readings
  • User defineable alphanumeric batching

Data Transfer

  • Bluetooth
  • PC compatible
  • USB connection, no software install required
  • Novo-Gloss MultiGauge analysis software

Measurement Area

  • 60: 6mm x 12mm
  • Operating Temperature: 15 - 40C (60 - 104F)
  • Humidity: Up to 85%, non condensing

Dimensions & Weight

  • Instrument: 80 x 150 x 35mm (H x W x D), 392g
  • Measurement head: 60 x 110 x 28mm (H x W x D),109g
  • Packed weight: 1.6kg
  • Packed dimensions: 110mm x 280mm x 220mm (H x W x D)
  • Commodity code: 9027 5000
