Datacolor 800-800V-850 Spectrophotometers
Datacolor 800 Spectrophotometers Close-tolerance color measurement for textiles, plastics, paint and coatings, and more.
Greater color accuracy means improved quality, faster turnaround times and reduced costs. When close tolerance is required, trust Datacolor 800 spectrophotometers to specify, formulate and control your colors.
Industries Covered: Industries that require the highest level of consistency across the supply chain, including retail brands, textile mills, and manufacturers of plastics, paint and coatings, flooring, furniture, cosmetics and more.
Unit Price: USD9,999/pc, contact us for latest pricing.
Download Datacolor 800 & 800V & 850 Brochure
Features
- Real-time communication of measurements
- Backward compatibility
- Accessibility for multiple users on a single instrument
- Fool-proof sample placement
- No profiling required—superior IIR right out of the box. Ensure accuracy across all instruments in your supply chain
- Our proprietary SP2000 optical technology lets you capture the true spectral fingerprint of any color at the highest accuracy
- Works seamlessly with your existing Datacolor 600 instruments
- Multiple users can easily use a single instrument
- Measurements can be taken and shared in real-time to streamline global communication
- 25% less time spent on measuring compared to DC600 instruments
- Faster response time in both standalone and networked environments
- Positioning Camera and LCD ensure proper sample placement every time
- Screen displays calibration status and instrument settings for smooth set-up
Specifications
| Feature | Datacolor 800 | Datacolor 800V | Datacolor 850 |
|---|---|---|---|
| Instrument type | Dual beam d/8º spectrophotometer | ||
| Illumination source | Pulsed xenon filtered to approximate D65 | ||
| Sphere diameter | 152 mm / 6 in | ||
| Wavelength Range | 360 nm -700 nm | ||
| Wavelength resolution | 2 nm | ||
| Reporting interval | 10 nm | ||
| Photometric range | 0-200% | ||
| Spectral analyzer | Proprietary SP2000 analyzer with dual 256 element diode array | ||
| 20 Read Repeatability on White Tile Using Double Flash (CIELAB) * |
0.01 (max) | ||
| Inter-instrument Agreement – Reflectance Measurements (CIELAB)* |
0.08 (avg) 0.15 (max) |
||
| Sample Positioning Camera | |||
| Lens | 4 position auto-zoom | ||
| Aperture Plates | 3 Standard LAV (30 mm illuminated, 26 mm measured) SAV (9 mm illuminated, 5 mm measured) USAV (6.5 mm illuminated, 2.5 mm measured) 2 Optional MAV (20 mm illuminated, 16 mm measured) XUSAV (3.0 mm illuminated, 2.5 mm measured) |
||
| Aperture Detection | |||
| Automated, adjustable UV Calibration | |||
| UV Cutoff Filters | 400 nm 420 nm 460 nm |
||
| Remote Measurement Button | |||
| Vertical Mount | |||
| Transmittance | |||
| Inter-instrument Agreement – Regular Transmittance at 550 nm |
±0.20% at 85% T ±0.10% at 32% T |
||
| Inter-instrument Agreement – Transmission Haze Measurements | ±0.15% at 10% TH | ||
| Transmission Sampling Aperture Size | 22 mm | ||
| Operating Environment | 5° to 40°C up to 85% RH, non-condensing | ||
| Physical Specifications (DC800) | Description | ||
| Color Display | 3.5 inch RGB LCD | ||
| Display Resolution | 320×240 pixel resolution | ||
| Weight | 37.5 lbs (16.6 kg) | ||
| Dimensions | 12.3” Wide X 13.2” Tall X 16.4” Deep (31.24 cm x 33.53 cm x 41.66 cm) |
||
| *Environmental Conditions: | Temperature 23°C +/- 1°C RH 44% +/- 1% |
||
